Image Sensor CIS x 2 (Duplex Scanner)
Optical Resolution 600 dpi
Interpolated Resolution 1200 dpi
Hardware Resolution 600 x 1200 dpi
Scan Modes Color: Input 48-bit, Output 24-bit
Grayscale: Input 16-bit, Output 8-bit
Black & White: 1-bit
ADF Capacity 1. 50 sheets (A4/ Letter, 70 g/㎡ or 18 Lbs), Max. thickness under 5mm (0.2").
2. 20 sheets (Business Cards).
3. Plastic Card, Max. thickness under 1.2 mm.
Note: Maximum ADF capacity varies, depending upon paper weight.
Scanning Speed ( ADF ) 30 ppm/ 60 ipm (Grayscale mode, 200 & 300 dpi, A4 Portrait)
30 ppm/ 60 ipm (B&W mode, 200 & 300 dpi, A4 Portrait)
30 ppm/ 60 ipm (Color mode, 200 & 300 dpi, A4 Portrait)
Note: Results may vary depending upon your scanning application, computer processor and system memory.
Acceptable Paper Sizes (W x L) Max: 220 x 5080 mm (8.66” x 200”)
Min: 63.5 x 50.8 mm (2.5” x 2”)
Daily Duty Scan ( Sheets ) 4,000
Action Button 3 Buttons: Up, Down, Scan.
9 Function Keys. All Customizable.
Power Supply 24 Vdc/ 0.75 A
Interface USB 2.0
RJ45 LAN (only support Windows)
Net Weight 1.66 Kgs | 3.66 Lbs
Dimensions (W x D x H) 263 x 128 x 148 mm | 10.36" x 5.02" x 5.83"
Protocol TWAIN Compliant
Operating System Windows XP / Vista / 7 / 8 / 10 / 11
macOS 10.8.x/ 10.9.x/ 10.10.x/ 10.11.x/ 10.12.x/ 10.13.x/ 10.14.x/ 10.15.x/ 11.x/ 12.x/ 13.x/ 14.x/ 15.x
Linux compatibility is only available for system integrators. Please contact sales@plustek.com for more info.
Hardware Requirements 3.2 GHz CPU processor or higher[1]
[1]Windows Recommended: 3.2 GHz Intel® Core™ i7 Processor with 4 CPU Cores or higher
4 GB RAM minimum (Recommended: 8 GB or more)
6 GB of hard-disk space for program installation
Display dimensions of 1024x768 or greater
Bundled Software Plustek DocAction
Plustek DocTWAIN
Scanner Search Tool
Built-in OCR Plustek OCR
(Powered by ABBYY® FineReader®)
