PlusTek SmartOffice S60 A3 Document Scanner
Image Sensor
CIS x 2
Light Source
LED
Optical Resolution
600 dpi
Interpolated Resolution
1200 dpi
Hardware Resolution
600 x 600 dpi
Scan Modes
Color: Input 48-bit, Output 24-bit
Grayscale: Input 16-bit, Output 8-bit
Black & White: 1-bit
ADF Capacity
1. 100 sheets (A4/ Letter, 70 g/㎡ or 18 Lbs), Max. thickness under 10 mm (0.4”)
2. 50 sheets (A3, 70 g/㎡ or 18 Lbs)
3. 20 sheets (Business Cards)
4. Plastic Card (Landscape Loading), Max. thickness under 1.2 mm, embossed cards can be scanned.
Note: Maximum ADF capacity varies, depending upon paper weight.
Scanning Speed ( ADF )
64 ppm/ 128 ipm (Color mode, 300 dpi, A4 Landscape)
64 ppm/ 128 ipm (Color mode, 200 dpi, A4 Landscape)
48 ppm/ 96 ipm (Color mode, 300 dpi, A4 Portrait)
48 ppm/ 96 ipm (Color mode, 200 dpi, A4 Portrait)
36 ppm/ 72 ipm (Color mode, 300 dpi, A3)
36 ppm/ 72 ipm (Color mode, 200 dpi, A3)
Note: Results may vary depending upon your scanning application, computer processor and system memory.
Scanning Area (W x L)
Max: 304.8 x 431.8 mm
Min: 13.2 x 13.2 mm
Long Paper: 304.8 x 5080 mm
Acceptable Paper Sizes (W x L)
Max: 304.8 x 431.8 mm
Min: 50.8 x 63.5 mm
Acceptable Paper Weight (Thickness)
40 to 220 g/㎡ (10 to 58 Lbs)
Multi-feed Detection
With ultrasonic technology
Daily Duty Scan ( Sheets )
18,000
Separate Roller Lifetime (Scans)
300,000
Pick Roller Lifetime (Scans)
300,000
Friction Roller Lifetime (Scans)
100,000
Action Button
5 Buttons: Power, Up, Down, Cancel, Scan
9 function keys are all customizable.
Power Supply
24 Vdc/ 1.25 A
Interface
USB 3.2 Gen 1 Type B x 1
Net Weight
6.8 kg
Dimensions (W x D x H)
405 x 272 x 297 mm
Protocol
TWAIN Compliant
Operating System
Windows 7 / 8 / 10 / 11
Linux compatibility is only available for system integrators. Please contact sales@plustek.com for more info.
Hardware Requirements
3.2 GHz CPU processor or higher[1]
[1]Windows Recommended: 3.2 GHz Intel® Core™ i7 Processor with 4 CPU Cores or higher
4 GB RAM minimum (Recommended: 8 GB or more)
6 GB of hard-disk space for program installation
USB Port: USB 3.0 Port (USB 2.0/1.1 supported)
Display dimensions of 1024x768 or greater
Bundled Software
Plustek DocAction
Plustek DocTWAIN
Built-in OCR
Plustek OCR
(Powered by ABBYY® FineReader®)
