Light Source LED
Optical Resolution 600 dpi
Hardware Resolution Flatbed: 1200 x 1200 dpi
ADF: 600 x 600 dpi
Scan Modes Color: Input 48-bit, Output 24-bit
Grayscale: Input 16-bit, Output 8-bit
Black & White: 1-bit
ADF Capacity 1. 50 sheets (A4/ Letter, 70 g/㎡ or 18 Lbs), Max. thickness under 5mm (0.2").
2. 20 sheets (Business Card)
Note: Maximum ADF capacity varies, depending upon paper weight.
Scanning Speed ( ADF ) 32 ppm/ 64 ipm (Color mode, 200 dpi, A4 Portrait)
32 ppm/ 64 ipm (Grayscale mode, 200 dpi, A4 Portrait)
32 ppm/ 64 ipm (B&W mode, 200 dpi, A4 Portr8it)
Note: Results may vary depending upon your scanning application, computer processor and system memory.
Scanning Area (W x L) Flatbed:
Max. 216 x 297 mm (8.5” x 11.69”)
Min. 12.7 x 12.7 mm (0.5” x 0.5”)
ADF:
Max. 216 x 356 mm (8.5” x 14”)
Min. 12.7 x 12.7 mm (0.5” x 0.5”)
Acceptable Paper Sizes (W x L) Flatbed:
Max. 216 x 297 mm (8.5” x 11.69”)
Min. 12.7 x 12.7 mm (0.5” x 0.5”)
ADF:
Max. 220 x 356 mm (8.66” x 14”)
Min. 90 x 50.8 mm (3.55” x 2”)
Acceptable Paper Weight (Thickness) 50 to 120 g/㎡ (14 to 32 Lbs)
Daily Duty Scan ( Sheets ) 3000
Roller Lifetime (Scans) 100000
Pad Lifetime (Scans) 25000
Action Button Scan、PDF、Custom
Power Supply 24 Vdc/ 0.75 A
Interface USB 2.0
Net Weight 3.98 Kgs | 8.77 Lbs
Dimensions (W x D x H) 418 x 326 x 101 mm | 16.45" x 12.83" x 4"
Protocol TWAIN Compliant
Operating System Windows XP / Vista / 7 / 8 / 10 / 11
Hardware Requirements 2.0 GHz CPU processor or higher[1]
[1]Windows Recommended: 2.8 GHz Intel® Core™ i5 Processor with 4 CPU Cores or higher
4 GB RAM minimum (Recommended: 8 GB or more)
6 GB of hard-disk space for program installation
Display dimensions of 1024x768 or greater
Bundled Software Plustek DocAction
Plustek DocTWAIN
Built-in OCR Plustek OCR
(Powered by ABBYY® FineReader®)
