• Scan Speed: 9 sec per scan (A3) Gray
• Resolution: 1200 dpi
• Scan Mode: 48-bit Color
• Duty Cycle: 2500 Scans per day
• Action Buttons: Copy, OCR, eMail, PDF
• Interface: USB 2.0
• Protocol: TWAIN Compliant
TECH SPECS:
Scanner Type Flatbed Scanner
Image Sensor CIS
Light Source LED
Optical Resolution 1200 dpi
Hardware Resolution 1200 dpi x 1200 dpi
Scan Modes Color: 48-bit input, 24-bit output
Grayscale: 16-bit input, 8-bit output
B/W: 1-bit output
Scanning Speed 8 sec (Color/Grayscale/B&W Mode, 300dpi, A3)
Scanning Area (W x L) Max. 297 x 431.8 mm (11.69" x 17")
Daily Duty Scan ( Sheets ) 2500 pages
Action Button Scan , E-mail , OCR , PDF
Power Supply AC Power: 24 V / 0.75 A
Interface USB 2.0
Net Weight 4.32 Kgs | 9.52 Lbs
Dimensions (W x D x H) 589 x 407 x 68 mm | 23.18" x 16.02" x 2.67"
Protocol TWAIN Compliant
Operating System Windows Vista / 7 / 8 / 10 / 11
macOS 10.10 / 10.11 / 10.12 / 10.13 / 10.14 / 10.15 / 11.x / 12.x / 13.x / 14.x / 15.x
Linux compatibility is only available for system integrators. Please contact sales@plustek.com for more info.
Hardware Requirements Windows and Mac
2.4 GHz CPU processor or higher[1][2][3]
[1]Windows Recommended: 2.8 GHz Intel® Core™ i5 Processor with 4 CPU Cores or higher
[2]Support Mac INTEL and M1 based processor
[3]Compatibility is not available with PowerPC
4 GB RAM minimum (Recommended: 8 GB or more, A3 size@1200 dpi scanning, allocated 20 GB Virtual Memory at minimum)
6 GB of hard-disk space for program installation
Display dimensions of 1024x768 or greater
Bundled Software Plustek DocAction
Plustek DocTWAIN
Plustek MacAction
Plustek ICA
Built-in OCR Plustek DocOCR (For Mac)
Plustek OCR (For Windows)
(Powered by ABBYY® FineReader®)
