• Scan Speed: 9 Sec per scan (Simplex / Color)
• Resolution: 600 dpi
• Max. Scan Size: 8.5 x 36 Inch
• Scan Mode: 48-bit Color
• Power: USB Powered
• Interface: USB 2.0
• Duty Cycle: 800 scans per day
• Net Weight: 400 grams
Image Sensor CIS
Light Source LED
Optical Resolution 600 dpi
Hardware Resolution 600 x 600 dpi
Scan Modes Color: 48-bit Input; 24-bit Output
Grayscale: 16-bit Input; 8-bit Output
B/W: 1-bit
Scanning Speed 9 sec (Color Mode, 300 dpi, A4)
Scanning Area (W x L) Maximum: 216 x 910 mm (8.5" x 36")
Minimum: 12.7 x 12.7 mm (0.5" x 0.5")
Acceptable Paper Sizes (W x L) Maximum: 216 x 910 mm (8.5" x 36")
Minimum: 74 x 52 mm (2.9" x 0.98")
* Place A8 card horizontal
Daily Duty Scan ( Sheets ) 800
Power Supply USB Power: 5V / 0.5A
Interface USB 2.0
Net Weight 0.41 Kgs | 0.91 Lbs
Dimensions (W x D x H) 295 x 50 x 40.5 mm | 11.61" x 1.97" x 1.59"
Protocol TWAIN Compliant
Operating System Windows 7 / 8 / 10 / 11
Linux compatibility is only available for system integrators. Please contact sales@plustek.com for more info.
Hardware Requirements 2.0 GHz CPU processor or higher[1]
[1]Windows Recommended: 2.8 GHz Intel® Core™ i5 Processor with 4 CPU Cores or higher
4 GB RAM minimum (Recommended: 8 GB or more)
6 GB of hard-disk space for program installation
BUS Powered
Display dimensions of 1024x768 or greater
Bundled Software Plustek DocAction
Plustek DocTWAIN
Built-in OCR Plustek OCR (For Windows)
(Powered by ABBYY® FineReader®)
