Synology DiskStation DS223 Desktop NAS Server
TECH SPECS:
Hardware Specifications
CPU
CPU Model Intel Celeron J4125
CPU Quantity 1
CPU Core 4
CPU Architecture 64-bit
CPU Frequency 2.0 (base) / 2.7 (turbo) GHz
Hardware Encryption Engine
Memory
System Memory 2 GB DDR4 non-ECC
Total Memory Slots 1
Maximum Memory Capacity 6 GB (2 GB + 4 GB)
Storage
Drive Bays 4
M.2 Drive Slots 2 (NVMe)
Drive Type (See all supported drives)
3.5" SATA HDD
2.5" SATA SSD
M.2 2280 NVMe SSD
Hot Swappable Drive*
Notes The hot swappable drive feature is not supported by M.2 SSD slots.
External Ports
RJ-45 1GbE LAN Port 2
USB 3.2 Gen 1 Port 2
Notes This device's 1GbE LAN ports have a maximum transmission unit (MTU) size of 1,500 bytes.
Appearance
Size (Height x Width x Depth) 166 mm x 199 mm x 223 mm
Weight 2.18 kg
Others
System Fan 92 mm x 92 mm x 2 pcs
Fan Speed Mode
Full-Speed Mode
Cool Mode
Quiet Mode
Brightness Adjustable Front LED Indicators
Power Recovery
Noise Level* 19.8 dB(A)
Scheduled Power On / Off
Wake on LAN / WAN
Power Supply Unit / Adapter 90 watts
AC Input Power Voltage 100V to 240V AC
Power Frequency 50/60 Hz, Single Phase
Power Consumption* 28.3 watts (Access)
8.45 watts (HDD Hibernation)
British Thermal Unit 96.5 BTU/hr (Access)
28.81 BTU/hr (HDD Hibernation)
Notes
For more information on how power consumption is measured, refer to this article.
Noise testing was conducted with the Synology system fully installed with Synology SATA HDDs and in an idle state. Two G.R.A.S. Type 40AE microphones are placed at a 1 m distance from the front and rear of the device. Background noise: 16.49-17.51 dB(A); Temperature: 24.25-25.75ËšC; Humidity: 58.2-61.8%
Temperature
Operating Temperature 0°C to 40°C (32°F to 104°F)
Storage Temperature -20°C to 60°C (-5°F to 140°F)
Relative Humidity 5% to 95% RH
