Synology DiskStation DS223 Desktop NAS Server
Enhanced Performance with Synology DS223
The Synology DS223 is a compact and efficient 2-bay NAS (Network Attached Storage) device designed for personal and small office use. It offers a reliable and secure platform for centralizing, organizing, and sharing your data. With its intuitive interface and advanced features, the DS223 makes it easy to create your own private cloud, access your files from anywhere, and protect your valuable data
Key Specifications :
CPU: Realtek RTD1619B quad-core processor (up to 1.7GHz)
Memory: 2GB DDR4 NON-ECC RAM (soldered)
Drive Bays: 2x 3.5″/2.5″ SATA III drive bays
Network: 1x Gigabit Ethernet port
Operating System: Synology DiskStation Manager (DSM)
Expansion: No expansion slots
TECH SPECS:
Synology DiskStation DS223
Hardware Specifications
CPU
CPU Model Realtek RTD1619B
CPU Quantity 1
CPU Core 4
CPU Architecture 64-bit
CPU Frequency 1.7 GHz
Hardware Encryption Engine Yes
Memory
System Memory 2 GB DDR4 non-ECC
Notes Synology reserves the right to replace memory modules with the same or higher frequency based on supplier’s product life cycle status. Rest assured that the compatibility and stability have been strictly verified with the same benchmark to ensure identical performance.
Storage
Drive Bays 2
Compatible Drive Type* (See all supported drives)
3.5″ SATA HDD
2.5″ SATA SSD
Hot Swappable Drive* Yes
Notes “Compatible drive type” indicates drives that have been tested to be compatible with Synology products. This term does not indicate the maximum connection speed of each drive bay.
External Ports
RJ-45 1GbE LAN Port 1
USB 3.2 Gen 1 Port* 3
USB Copy Yes
Notes
This device’s 1GbE LAN ports have a maximum transmission unit (MTU) size of 1,500 bytes.
The USB 3.0 standard was renamed to USB 3.2 Gen 1 by the USB Implementers Forum (USB-IF) in 2019.
Appearance
Size (Height x Width x Depth) 165 mm x 108 mm x 232.7 mm
Weight 1.28 kg
Others
System Fan 92 mm x 92 mm x 1 pcs
Fan Speed Mode
Full-Speed Mode
Cool Mode
Quiet Mode
Brightness Adjustable Front LED Indicators Yes
Power Recovery Yes
Noise Level* 14.6 dB(A)
Scheduled Power On / Off Yes
Wake on LAN / WAN Yes
Power Supply Unit / Adapter 60 watts
AC Input Power Voltage 100V to 240V AC
Power Frequency 50/60 Hz, Single Phase
Power Consumption 17.343 watts (Access)
4.08 watts (HDD Hibernation)
British Thermal Unit 59.19 BTU/hr (Access)
13.92 BTU/hr (HDD Hibernation)
Notes
For more information on how power consumption is measured, refer to this article.
Noise testing was conducted with the Synology system fully installed with Synology SATA SSDs and in an idle state. Two G.R.A.S. type 40AE microphones were placed at a 1 m distance from the front and rear of the device. Background noise: 16.49-17.51 dB(A); Temperature: 24.25-25.75ËšC; Humidity: 58.2-61.8%.
Temperature
Operating Temperature 0°C to 40°C (32°F to 104°F)
Storage Temperature -20°C to 60°C (-5°F to 140°F)
Relative Humidity 5% to 95% RH
Certification
FCC
CE
BSMI
VCCI
RCM
UKCA
EAC
CCC
KC
Environment
RoHS Compliant
Synology DiskStation DS223
Packaging Content
Main Unit X 1
Accessory Pack X 1
AC Power Adapter X 1
AC Power Cord X 1
RJ-45 LAN Cable X 1
Quick Installation Guide X 1
