Intel® Core™ i9 processor 14900K
CPU Specifications
-
Total Cores24
-
# of Performance-cores8
-
# of Efficient-cores16
-
Total Threads32
-
Max Turbo Frequency6 GHz
-
Intel® Thermal Velocity Boost Frequency6 GHz
-
Intel® Turbo Boost Max Technology 3.0 Frequency ‡5.8 GHz
-
Performance-core Max Turbo Frequency5.6 GHz
-
Efficient-core Max Turbo Frequency4.4 GHz
-
Performance-core Base Frequency3.2 GHz
-
Efficient-core Base Frequency2.4 GHz
-
Cache36 MB Intel® Smart Cache
-
Total L2 Cache32 MB
-
Processor Base Power125 W
-
Maximum Turbo Power253 W
Supplemental Information
Memory Specifications
-
Max Memory Size (dependent on memory type)192 GB
-
Memory TypesUp to DDR5 5600 MT/s
Up to DDR4 3200 MT/s
-
Max # of Memory Channels2
-
Max Memory Bandwidth89.6 GB/s
-
ECC Memory Supported ‡Yes
GPU Specifications
-
Processor Graphics ‡Intel® UHD Graphics 770
-
Graphics Base Frequency300 MHz
-
Graphics Max Dynamic Frequency1.65 GHz
-
Graphics OutputeDP 1.4b, DP 1.4a, HDMI 2.1
-
Execution Units32
-
Max Resolution (HDMI)‡4096 x 2160 @ 60Hz
-
Max Resolution (DP)‡7680 x 4320 @ 60Hz
-
Max Resolution (eDP - Integrated Flat Panel)‡5120 x 3200 @ 120Hz
-
DirectX* Support12
-
OpenGL* Support4.5
-
OpenCL* Support3.0
-
Multi-Format Codec Engines2
-
Intel® Quick Sync VideoYes
-
Intel® Clear Video HD TechnologyYes
-
# of Displays Supported ‡4
-
Device ID0xA780
Expansion Options
-
Direct Media Interface (DMI) Revision4.0
-
Max # of DMI Lanes8
-
Scalability1S Only
-
PCI Express Revision5.0 and 4.0
-
PCI Express Configurations ‡Up to 1x16+4, 2x8+4
-
Max # of PCI Express Lanes20
Package Specifications
-
Sockets SupportedFCLGA1700
-
Max CPU Configuration1
-
Thermal Solution SpecificationPCG 2020A
-
TJUNCTION100°C
-
Package Size45.0 mm x 37.5 mm
Advanced Technologies
-
Intel® Gaussian & Neural Accelerator3.0
-
Intel® Thread DirectorYes
-
Intel® Deep Learning Boost (Intel® DL Boost) on CPUYes
-
Intel® Speed Shift TechnologyYes
-
Intel® Adaptive Boost TechnologyYes
-
Intel® Thermal Velocity BoostYes
-
Intel® Turbo Boost Max Technology 3.0 ‡Yes
-
Intel® Turbo Boost Technology ‡2.0
-
Intel® Hyper-Threading Technology ‡Yes
-
Intel® 64 ‡Yes
