Intel® Core™ i9 processor 14900K
CPU Specifications
Total Cores24
# of Performance-cores8
# of Efficient-cores16
Total Threads32
Max Turbo Frequency6 GHz
Intel® Thermal Velocity Boost Frequency6 GHz
Intel® Turbo Boost Max Technology 3.0 Frequency ‡5.8 GHz
Performance-core Max Turbo Frequency5.6 GHz
Efficient-core Max Turbo Frequency4.4 GHz
Performance-core Base Frequency3.2 GHz
Efficient-core Base Frequency2.4 GHz
Cache36 MB Intel® Smart Cache
Total L2 Cache32 MB
Processor Base Power125 W
Maximum Turbo Power253 W
Supplemental Information
Marketing StatusLaunched
Launch DateQ4'23
Embedded Options AvailableNo
Memory Specifications
Max Memory Size (dependent on memory type)192 GB
Memory TypesUp to DDR5 5600 MT/s
Up to DDR4 3200 MT/s
Max # of Memory Channels2
Max Memory Bandwidth89.6 GB/s
ECC Memory Supported ‡Yes
GPU Specifications
Processor Graphics ‡Intel® UHD Graphics 770
Graphics Base Frequency300 MHz
Graphics Max Dynamic Frequency1.65 GHz
Graphics OutputeDP 1.4b, DP 1.4a, HDMI 2.1
Execution Units32
Max Resolution (HDMI)‡4096 x 2160 @ 60Hz
Max Resolution (DP)‡7680 x 4320 @ 60Hz
Max Resolution (eDP - Integrated Flat Panel)‡5120 x 3200 @ 120Hz
DirectX* Support12
OpenGL* Support4.5
OpenCL* Support3.0
Multi-Format Codec Engines2
Intel® Quick Sync VideoYes
Intel® Clear Video HD TechnologyYes
# of Displays Supported ‡4
Device ID0xA780
Expansion Options
Direct Media Interface (DMI) Revision4.0
Max # of DMI Lanes8
Scalability1S Only
PCI Express Revision5.0 and 4.0
PCI Express Configurations ‡Up to 1x16+4, 2x8+4
Max # of PCI Express Lanes20
Package Specifications
Sockets SupportedFCLGA1700
Max CPU Configuration1
Thermal Solution SpecificationPCG 2020A
TJUNCTION100°C
Package Size45.0 mm x 37.5 mm
Advanced Technologies
Intel® Gaussian & Neural Accelerator3.0
Intel® Thread DirectorYes
Intel® Deep Learning Boost (Intel® DL Boost) on CPUYes
Intel® Speed Shift TechnologyYes
Intel® Adaptive Boost TechnologyYes
Intel® Thermal Velocity BoostYes
Intel® Turbo Boost Max Technology 3.0 ‡Yes
Intel® Turbo Boost Technology ‡2.0
Intel® Hyper-Threading Technology ‡Yes
Intel® 64 ‡Yes
