Product Dimension (W × H × D)
248.40 mm × 154.80 mm × 213.34 mm (9.78"× 6.09"× 8.40")
Package Dimension (W × H × D)
306 mm × 290 mm × 59 mm (12.05"× 11.42"× 2.32")
Net Weight
0.222 kg (0.489 lb)
Packing List
Wireless Router x 1, Ethernet cable × 1, Quick installation guide × 1
Packing Method
Single pack
Working Temperature
0 ℃ to 40 ℃ (32 ℉ to 104 ℉)
Working Humidity
10% to 90% RH non-condensing
Storage Temperature
-40 ℃ to 70 ℃ (-40 ℉ to 158 ℉)
Storage Humidity
5% to 90% RH non-condensing
Installation Mode
Desktop installation
Max. Power Consumption
≤ 9 W
Gross Weight
0.722 kg (1.592 lb)
Wireless Parameter
Data Rate
≤ 1167 Mbps
2.4 GHz: 300 Mbps
5 GHz: 867 Mbps
Wireless Standard
IEEE 802.11/a/n/ac wave 2 @5GHz, IEEE 802.11b/g/n @2.4GHz
Working Frequency Band
2.4 GHz，5 GHz
Transmitting Power
CE:
<20 dBm(2.4G)
<23 dBm(5G)
Wireless Performance
4 × 4 MU-MIMO supported
Beamforming supported
Receiving Sensitivity
58 ± 2 dB@AC80 -MCS9
84 ± 2 dB@AC80 -MCS0
Antenna
4 high gain antennas
Operating Frequency
2.4 GHz: US/2412-2472 MHz(CH1-CH13)
5 GHz: US/5180-5240 MHz(CH36-CH48)
5 GHz: US/5740-5805 MHz(CH149-CH161)
EIRP Power(Max.)
2.4 GHz: 19.86 dBm
5 GHz: 22.96 dBm
Hardware Parameter
Network Interface
1*10/100Mbps WAN port 3*10/100Mbps LAN ports
LED Indicator
LED indicator
Reset
Reset button
Power Supply Method
9 VDC, 1 A power adapter power supply
Power Specifications
9 VDC, 1 A
Software Function
Application Function
Wireless Router Mode, Wireless Repeater Mode, Client + AP, WISP, and AP Mode supported
DHCP Server supported
Guest Network Configuration supported
Signal Adjustment supported
WiFi Schedule supported
Security Mode
WPA-PSK, WPA2-PSK, WPA and WPA2 supported
Security Mechanism
Hide SSID
Management Method
Web
Upgrade
Web Update and Upgrade
System Log
System log
