650VA/375 Watt

Automatic self-test:

Periodic battery self-test ensures early detection of a battery that needs to be replaced.

Automatic Voltage Regulation (AVR):

Automatically steps up low voltage and steps down high voltage to levels that are suitable for your equipment.

Back-UPS Features & Benefits:

Protection:

Surge only outlets:

Protect secondary electronics from surges and spikes without reducing battery power used to run primary electronics during an outage.

Battery and surge protected outlets:

Back up and protect your hardware and data during power outages, surges and spikes.

Availability:

Automatic self-test:

Periodic battery self-test ensures early detection of a battery that needs to be replaced.

Battery failure notification:

Provides early-warning fault analysis on batteries enabling timely preventive maintenance

Intelligent battery management:

Maximizes battery performance, life, and reliability through intelligent, precision charging.

Safety:

Safety-agency approved:

Ensures the product has been tested and approved to work safely with the connected service provider equipment and within the specified environment.

Manageability:

Audible alarms:

Provides notification of changing utility power and UPS power conditions

LED status display:

Quickly understand unit and power status with visual indicators.

Marketing features:

Battery-protected and surge-only outlets:

Reserves power capacity and run time for connected equipment that require UPS battery back-up while providing surge only protection for less critical equipment

Specifications:

Output:

Max Configurable Power (Watts):

325 Watts / 650VA

Output Frequency (sync to mains):

50/60 Hz +/- 1 Hz Sync to mains

Topology:

Line interactive

Waveform type:

Stepped approximation to a sinewave

Transfer Time:

4 ms typical : 6 ms maximum

Input:

Input frequency:

50/60 Hz +/- 3 Hz Auto-sensing

Input voltage range for main operations:

180 - 270V

Number of Power Cords:

1

Type of Input Protection Required:

GL fuse

Input Power Factor at Full Load:

0.5

Batteries & Runtime:

Battery type:

Lead-acid battery

Included Battery Modules:

1

Typical recharge time:

4hour(s)

Replacement Battery:

APCRBC110

Expected Battery Life (years):

2 – 4

Battery Charge Power (Watts):

19 Watts

Efficiency:

View Efficiency Graph

Communications & Management:

Control panel:

LED Status display with on line: on battery

Audible Alarm:

Alarm when on battery: distinctive low battery alarm : overload continuous tone alarm

Surge Protection and Filtering:

Surge energy rating:

160Joules

Physical:

Maximum Height:

141MM, 14.1CM

Maximum Width:

101MM, 10.1CM

Maximum Depth:

300MM, 30.0CM

Net Weight:

4.33KG

Shipping weight:

4.58KG

Shipping Height:

223MM, 22.3CM

Shipping Width:

143MM, 14.3CM

Shipping Depth:

347MM, 34.7CM

Color:

Black

Master Carton Dimensions (Length x Width x Height):

584 x 356 x 229MM

Master Carton Units:

4.0

Master Carton Weight:

18.5

Pallet Dimensions:

47.24 x 39.37 x 44.88inches

# of Layers per Pallet:

4.0

# of Units per Layer per Pallet:

20.0

Pallet Weight:

892.87lbs.

Units per Pallet:

80.0

SCC Codes:

10731304318184

Environmental:

Operating Temperature:

0 - 40 °C:

Operating Relative Humidity:

0 - 95 %

Operating Elevation:

0 - 1999.79meters

Storage Temperature:

-20 - 50 °C

Storage Relative Humidity:

0 - 95 %

Storage Elevation:

0 - 14999.8meters

Audible noise at 1 meter from surface of unit:

40.0dBA

Sustainable Offer Status:

RoHS:

Compliant
