Display
Panel Size: 55"
Type/Tech: TFT LCD Module with DLED Backlight.
Display Area (mm): 1209.6(H) x 680.4 (V) (54.64” diagonal)
Aspect Ratio: 16:9
Native Resolution: UHD 3840x2160(Pixels)
Colours: 1.07B colours (10bit)
Brightness: 350 nits (typ.) 300 nits (min.)
Contrast Ratio: 5000:1 (DCR)
Response Time: 8ms
Viewing Angles: H = 178, V = 178 typ.
Backlight Life: 30,000 Hours (Min)
Surface Treatment: Anti-Glare
Bezel: Slim
Orientation: Landscape
Platform
Processor: ARM Cortex A73 dual-core 1.2GHz
RAM: 2GB DDR4
Storage: 16GB
Touch
Type/ Tech: IR Recognition
Touch Resolution: 32767 x 32767
Touch Point: 20 points touch, 10 points writing
INPUT
HDMI: 2.0 x3 (3840x2160 @60Hz)
RGB / VGA: x1
Audio: x1 (PC audio in)
CVBS: x1
RS232: x1
OPS: x1 PC Slot (proprietary)
OUTPUT
HDMI: x1
Audio: x1 (Earphone out)
SPDIF: 1(optical)
LAN
RJ45: x1
USB
Type A: USB 2.0 x4(including 2 USB port in front)
USB 3.0 x2(including 1 USB port in front)
Type B: x2, for touch
SPEAKERS
SPEAKERS: 10W x 2 + 15W x 1
Embedded OS
Embedded OS: Android 7
USB SUPPORTED FILE FORMAT
USB SUPPORTED FILE FORMAT: Picture -
BMP, JPEG, PNG
Video -
Codec: MPEG1, MPEG2, MPEG2-PS, MPEG4, MKV
Container: MPG, MP4, MOV, VOB, DAT, MKV
Audio -
Codec: AAC, HEAAC, MPEG1, MPEG2
Container: AAC, M4A, MP3
Bundle Software
Basic Annotation Software: myViewBoard / vBoard Lite
Pro Annotation Software: myViewBoard for windows (Embedded in Windows Slot-in PC)
Wireless Presentation with Touch Feedback: Viewboard Cast: yes
ViewSonic Launcher: Embedded
Special Features
All-in-one USB port (combine Windows/Android USB port; no need to distinguish them anymore): Front “SmartPort™ USB” to all channels.
Simple LAN sharing between IFP and slot-in device: Yes
Power
Voltage: 100-240VAC +/- 10% Wide Range
Consumption: 81W (Typ.)
< 0.5 W ("Off")
ERGONOMICS
Wall Mount (VESA® ): 400 x 200
OPERATING CONDITIONS
Temperature (º C): 0°C to 40°C
Humidity: 10% ~ 90% RH non-condensing
DIMENSIONS (W x H x D)
Physical (inch / mm): 49.9 x 30.4 x 3.3 in / 1268 x 773 x 85 mm
Packaging (inch / mm): 56.2 x 34.6 x 8.7 in / 1428 x 878 x 220 mm
WEIGHT
Net (lb / kg): 68.34 lb / 31 Kg
Gross (lb / kg): 85.98 lb / 39 Kg
REGULATIONS
REGULATIONS: FCC, cTUVus, CB, CE, BSMI, RCM, EAC
Energy Star version
Energy Star version: ES8.0
EEI rating
EEI rating: A+
PACKAGE CONTENTS
PACKAGE CONTENTS: 1. Power cable (3 meters) x 4
2. Remote control
3.USB cable (3 meters)
4. AV cable
5. Touching pen x 2
6. Quick Start Guide
7. RS232 adapter
8. Clamp x 5
9. Plate
10. Screw x 8
11. HDMI cable
Compatible Slot-in PC
Compatible Slot-in PC: VPC14-WP series
VPC10-WP series
VPC15-WP series
VPC16-WP series
VPC17-WP series
