As an upgrade to the classic D4-300, the D4-320 offers several revolutionary changes while maintaining affordability. Its new design concept offers a stylish and minimalist appearance that is more aesthetically pleasing, while its underlying technology offers a qualitative leap in terms of performance, allowing users to access outstanding functionality.
TECH SPECS:
Storage
Disk Slot Number 4
Compatible Disk Types 3.5" SATA HDD
2.5" SATA HDD
2.5" SATA SSD
File System NTFS, APFS, Mac OS,FAT32,EXT4,exFAT
Maximum Internal Raw Capacity 88 TB (22 TB drive x 4)
RAIDs Supported SINGLE DISK
Hardware RAID /
RAID Manager Software /
RAID Manager Software Language /
RAID Online Expansion /
RAID Migration /
RAID Auto-rebuilding /
Drive Hot Swap √
HDD Sleep √
HDD S.M.A.R.T. Inspection /
Sector Inspection and Parity Check /
SSC Cache /
Daisy Chain /
HDD NCQ Technology /
Alert Notice /
Event Log /
External Ports
USB USB3.2 Type-C gen2 10Gbps
Thunderbolt /
DP Interface /
Network Interface /
USB HOST Interface /
Power Socket DC IN 12V
Reading/writing Speed (max.)
Reading Speed (max.) Read：560MB/s ( SSD* 1 ); Read：1016MB/s ( SSD* 4)；
Writing Speed (max.) Write：520MB/s ( SSD*1 ); Write：960MB/s ( SSD*4 )；
Appearance
Size (H*W*D) 222 x 179 x 154 mm
Packaging Size (H*W*D) 300 x 275 x 186 mm
Weight net weight: 1.9Kg Gross Weight:3.1 Kg
Others
System fan 120 x 120 x 25mm 1PCS
Fan mode Smart
Noise Level 21.0dB(A)
Power Supply
Power Supply 72 W
AC Input Voltage 100V to 240V AC
Current Frequency 50/60 HZ, Single Phase
Power Consumption 40.8 W(Access), 9.8 W (Hibernation)
Environment Temperature
Working Temperature 0°C ~ 40°C (32°F ~ 104°F)
Storage Temperature -20°C ~ 60°C (-5°F ~ 140°F)
Relative Humidity 5% ~ 95% RH
Supported OS Windows OS、Mac OS、Linux
Warranty 2 years
Certificate CE, FCC, CCC, KC
Environment RoHS compliance
Package Contents: Host unit (x1)
Power cord (x1)
USB Cable C to Type-C(10Gb) (0.8m x1)
Quick Installation Guide (x1)
Power adapter (x1)
Screws (several)
Limited Warranty Note x 1
