Specifications

CPU

CPU Model

AMD Ryzen R1600

CPU Quantity

1

CPU Architecture

64-bit

CPU Frequency

2-core 2.6 (base) / 3.1 (turbo) GHz

Hardware Encryption Engine

Memory

System Memory

4 GB DDR4 ECC SODIMM

Memory Module Pre-installed

4 GB (4 GB x 1)

Total Memory Slots

2

Maximum Memory Capacity

32 GB (16 GB x 2)

Notes

• Synology reserves the right to replace memory modules with the same or higher frequency based on supplier's product life cycle status. Rest assured that the compatibility and stability have been strictly verified with the same benchmark to ensure identical performance.

Storage

Drive Bays

4

Maximum Drive Bays with Expansion Unit

9 (DX517 x 1)

M.2 Drive Slots

2 (NVMe)

Compatible Drive Type*

• 3.5" SATA HDD

• 2.5" SATA SSD

• M.2 2280 NVMe SSD

Hot Swappable Drive*

Notes

• "Compatible drive type" indicates drives that have been tested to be compatible with Synology products. This term does not indicate the maximum connection speed of each drive bay.

External Ports

RJ-45 1GbE LAN Port

2 (with Link Aggregation / Failover support)

USB 3.2 Gen 1 Port*

2

eSATA Port

1

Notes

• This device's 1GbE LAN ports have a maximum transmission unit (MTU) size of 1,500 bytes.

PCIe

PCIe Expansion

1 x Gen3 x2 network upgrade slot

Appearance

Size (Height x Width x Depth)

166 mm x 199 mm x 223 mm

Weight

2.24 kg

Others

System Fan

92 mm x 92 mm x 2 pcs

Fan Speed Mode

• Full-Speed Mode

• Cool Mode

• Quiet Mode

Brightness Adjustable Front LED Indicators

Power Recovery

Noise Level*

22.9 dB(A)

Scheduled Power On / Off

Wake on LAN / WAN

Power Supply Unit / Adapter

100 W

AC Input Power Voltage

100V to 240V AC

Power Frequency

50/60 Hz, Single Phase

Power Consumption

35.51 W (Access)
11.52 W (HDD Hibernation)

British Thermal Unit

121.09 BTU/hr (Access)
39.28 BTU/hr (HDD Hibernation)

Notes

• Noise testing was conducted with the Synology system fully installed with Synology SATA HDDs and in an idle state. Two GRAS 40AE microphones are placed at a 1 m distance from the front and rear of the device. Background noise: 16.49-17.51 dB(A); Temperature: 24.25-25.75˚C; Humidity: 58.2-61.8%

Temperature

Operating Temperature

0°C to 40°C (32°F to 104°F)

Storage Temperature

-20°C to 60°C (-5°F to 140°F)

Relative Humidity

5% to 95% RH

Certification

• FCC

• CE

• BSMI

• VCCI

• RCM

• UKCA

• EAC

• CCC

• KC

Warranty

Environment

RoHS Compliant

Packaging Content

• Main Unit X 1

• Accessory Pack X 1

• AC Power Adapter X 1

• AC Power Cord X 1

• RJ-45 LAN Cable X 2

• Quick Installation Guide X 1
