LCD Panel
|
Display size
|
24" Diagona WLED Backlight
|
|
Brightness(Typical)
|
250cd/m2 (Typical)
|
|
NTSC
|
NTSC 72%
|
|
Contrast(Typical)
|
3000:1 (Typical)
|
|
Pixel Pitch
|
0.5213952（H）X 0.2932848（V）
|
|
Resolution (H x V)
|
1920*1080
|
|
Aspect Ratio
|
16:09
|
|
Response Time(Typical)
|
GTG 4ms
|
|
View Angles LR,UD(CR>10)
|
H 178/ V178
|
|
Panel Surface
|
Anti-glare
|
|
Display Colors
|
16.7M colors
|
|
|
Vertical Freq.
|
180Hz
|
|
Max. display frequency
(Resolution H*V/Fv)
|
1920 x 1080 @ 144 Hz
|
|
Interface
|
Input 1
|
HDMI 1.4
|
|
Input 2
|
HDMI 1.4
|
|
Input 3
|
DP
|
|
Input 4
|
N/A
|
|
Output
Terminal
|
Earphone
|
Audio out
|
|
Speaker(Typic )
|
NA
|
|
Power
|
Consumption(Typical)
|
On: ≤30W
Standby<=0.5W, Off<=0.5W
|
|
Power Range
|
AC 100-240V 50/60Hz
|
|
Power Mode
Indicator Light
|
Power on : White(LED)
Power saving : white Flicker (LED)
|
|
Operating
Condition
|
Temperature
|
0℃ ~ 45℃
|
|
Humidity
|
10% ~90%, non-condensing
|
|
Physical
|
Dimension
(W*D*H)
|
536.66 x 185.06 x 406.94mm
|
|
Packing Dimension
(W*D*H)
|
618 x 145 x 418mm
|
|
Net Weight
|
4.1KG
|
|
Gross Weight
|
5.47KG
|
|
Tilt
|
-5∘~ 15∘
|
|
High Adjustable Arm
|
NA
|
|
Swivel
|
NA
|
|
Pivot
|
NA
|
|
Kensington Lock
|
Yes
|
|
VESA Mounting
|
75*75 mm
|
|
Controls
|
Front Control
|
Menu, Up(+),Down(-), Enter, Power
|
|
On Screen Display
|
HKC 2015 new OSD
|
|
Color
|
WARM,COOL,User Mode
|
|
Preset Mode
|
PC, Movie, Game, ECO Modes
|
|
Accessory
|
Power Cable
|
N/A
|
|
Adapter
|
DC 12V，2.5A
|
|
VGA Cable
|
NA
|
|
Audio Cable
|
NA
|
|
DVI Cable
|
NA
|
|
HDMI-DVI Cable
|
NA
|
|
HDMI-HDMI Cable
|
NA
|
|
DP Cable
|
Yes (1.5M)
|
|
User Manual(Paper)
|
YES
|
