Picture/Display
Panel Size
34 inch / 86.36 cm
Aspect ratio
21:9
LCD panel type
VA LCD
Backlight type
W-LED system
Pixel pitch
0.23175 x 0.23175 mm
Brightness
300 cd/m²
Display colors
16.7 M
Color gamut (typical)
NTSC 99.25%*, sRGB 123.24%*
Contrast ratio (typical)
3000:1
SmartContrast
Mega Infinity DCR
Response time (typical)
4 ms (Gray to Gray)*
Viewing angle
178º (H) / 178º (V)
@ C/R > 10
Picture enhancement
SmartImage game
Maximum resolution
3440 x 1440 @ 100 Hz*
Effective viewing area
797.22 (H) x 333.72 (V) - at a 1500R curvature*
Scanning Frequency
30 - 160 kHz (H) / 48 - 100 Hz (V)
sRGB
Yes
Flicker-free
Yes
Pixel Density
109.68 PPI
LowBlue Mode
Yes
Display Screen Coating
Anti-Glare, 3H, Haze 25%
MPRT
1 ms
EasyRead
Yes
Adaptive sync
Yes
Connectivity
Signal Input
HDMI 2.0 x 1, DisplayPort 1.2 x 1, USB-C x 1 (DisplayPort Alt mode, data and Power Delivery)
Sync Input
Separate Sync
Audio (In/Out)
Audio out
HDCP
HDCP 1.4 (HDMI / DisplayPort / USB-C), HDCP 2.2 (HDMI / DisplayPort / USB-C)
USB Hub
USB 3.2 Gen 1, USB-A downstream x 4 (with 1 fast charge B.C 1.2)
Power Delivery
Max power delivery
USB-C: Up to 65W (5V/3A, 7V/3A, 9V/3A, 10V/3A, 12V/3A, 15V/3A, 20V/3.25A)
Version
USB PD version 3.0
Convenience
Built-in Speakers
5 W x 2
Plug & Play Compatibility
DDC/CI
Mac OS X
sRGB
Windows 10 / 8.1 / 8 / 7
User convenience
Power On/Off
Menu
Volume
Input
SmartImage Game
OSD Languages
Brazil Portuguese
Czech
Dutch
English
Finnish
French
German
Greek
Hungarian
Italian
Japanese
Korean
Polish
Portuguese
Russian
Simplified Chinese
Spanish
Swedish
Traditional Chinese
Turkish
Ukrainian
Other convenience
Kensington lock
VESA mount (100x100mm)
MultiView
PIP/PBP mode
2x devices
Built-in webcam
5.0 megapixel camera with microphone and LED indicator
Noise cancellation
Yes
Stand
Height adjustment
130 mm
Tilt
-5/20 degree
Power
Power supply
Internal
100-240VAC, 50-60Hz
Off mode
0.3 W (typ.)
On mode
57.0 W (typ.)
Standby mode
0.5 W (typ.)
Power LED indicator
Operation - White
Standby mode- White (blinking)
Dimensions
Product with stand (mm)
808 x 557 x 281 mm
Product with stand in inch
31.8 x 21.9 x 11.1 inch
Packaging in mm (WxHxD)
980 x 519 x 226 mm
Product without stand (mm)
808 x 381 x 111 mm
Packaging in inch (WxHxD)
38.6 x 20.4 x 8.9 inch
Product without stand in inch
31.8 x 15 x 4.4 inch
Weight
Product with packaging (kg)
12.43 kg
Product with stand (kg)
9.29 kg
Product with packaging (lb)
27.35 lb
Product with stand (lb)
20.44 lb
Product without stand (kg)
7.16 kg
Product without stand (lb)
15.75 lb
Operating conditions
Altitude
Operation: +12,000ft (3,658m), Non-operation: +40,000ft (12,192m)
Temperature range (operation)
0 to 40 °C
MTBF
50,000 (excluding backlight) hour(s)
Relative humidity
20%-80 %
Temperature range (storage)
-20 to 60 °C
Sustainability
Environmental and energy
RoHS
Recyclable packaging material
100 %
Specific Substances
Mercury free
PVC / BFR free housing
Compliance and standards
Regulatory Approvals
CB
CE Mark
CU-EAC
EAEU RoHS
FCC Class B
ICES-003
TUV/ISO9241-307
TUV-BAUART
Cabinet
Color
Black
Finish
Textured
What's in the box?
Cables
HDMI cable, DisplayPort cable, USB-C to USB-C cable, Power cable
Monitor with stand
Yes
User Documentation
Yes
