MSI MAG CORELIQUID E360 AIO Liquid Intel LGA 1700 & AMD AM5 Gaming CPU Cooler-Black
-
MSI's TORX FAN 4.0 provides supreme cooling to the radiator.
-
60 mm TORX FAN 3.0 within the water block provides heat dissipation to the power solutions.
-
2.4” Customizable IPS display: hardware monitor, video & image upload, system clock and live weather.
-
The fan and pump speed can be independently controlled according to different user scenarios.
-
Latest CPU socket supported: Intel LGA 1700 & AMD AM5.
-
A three-layer mesh plastic tube slows down the evaporation speed of water cooling liquid.
-
The enlarged copper base surface area helps to achieve ultimate heat exchange with the latest CPU generation.
-
Maximize micro-channels to dissipate heat efficiently
-
Rotatable water block cap for 270-degree.
-
ARGB fan can change the lighting by MSI center.
-
Enhanced fan performance to dissipate heat quickly.
-
Durable three phase motor of the pump generates minimal vibrations for long-lasting operation.
-
Spilt pathway through the radiator rapidly dissipates heat.
TECH SPECS:
|
Model
|
|
Brand
|
MSI
|
|
Model
|
MAG CORELIQUID E360
|
|
Type
|
Liquid Cooling System
|
|
Block
|
|
Block Compatibility
|
AMD Socket AM4 / AMD Socket AM5 / AMD Socket sTR4 / Intel LGA 1150 / Intel LGA 1151 / Intel LGA 1155 / Intel LGA 1156 / Intel LGA 1200 / Intel LGA 1700
|
|
Block Dim.
|
41 (+/-0.2) x 47.6 (+/-0.2) mm
|
|
Block Material
|
Copper
|
|
Radiator
|
|
Radiator Size
|
Radiator Size: 360 mm
Radiator Dimensions: 394 x 119.2 x 27mm / 15.51 x 4.69 x 1.06 inches
|
|
Radiator Material
|
Aluminum
|
|
Fan
|
|
Fan Size
|
3 Fan Slots (120 mm)
|
|
Fan Dim.
|
120 x 120 x 25mm / 4.7 x 4.7 x 0.98 inches
|
|
Bearing Type
|
Fluid Dynamic Bearing (FDB)
|
|
Fan RPM
|
600 +/-250RPM ~ 1800 +/-200RPM
|
|
Fan Air Flow
|
25.5~75.04 CFM
|
|
Fan Noise
|
11.2~32.5 dBA
|
|
Fan Connector
|
Pin + Socket
|
|
Color
|
Black
|
|
LED Color
|
ARGB
|
|
Tube
|
|
Tube Dim.
|
Water Cooling Tube Length: 400mm / 15.75 inches
|
|
Tube Material
|
Black Rubber
|
|
Features
|
|
Features
|
The enlarged copper base surface area helps to achieve ultimate heat exchange with the latest CPU generation
Maximize micro channels to dissipate heat efficiently
Rotatable water block cap for 270 degree.
ARGB fan can change the lighting by MSI center.
Enhanced fan performance to dissipate heat quickly.
Pump is separating the rooms of cool water and hot water to avoid mixing water temperatures and effectively reduce the heat source.
Durable three phase motor of the pump generates minimal vibrations for long lasting operation.
Spilt pathway through the radiator rapidly dissipates heat.
|
|
Package Contents
|
|
Package Contents
|
1 to 3 Fan PWM cable x 1
Molex 4-Pin to 4-Pin fan cable x 1
Noise reducer cable x 1
Thermal paste x 1
|
