Product Collection

Code Name

Vertical Segment Desktop

Processor Numberi5-14600K

Lithography Intel 7

Use Conditions PC/Client/Tablet, Workstation

Total Cores14

# of Performance-cores6

# of Efficient-cores8

Total Threads20

Max Turbo Frequency5.3 GHz

Performance-core Max Turbo Frequency5.3 GHz

Efficient-core Max Turbo Frequency4 GHz

Performance-core Base Frequency3.5 GHz

Efficient-core Base Frequency2.6 GHz

Cache24 MB Intel® Smart Cache

Total L2 Cache20 MB

Processor Base Power125 W

Maximum Turbo Power181 W

Marketing Status Launched

Launch DateQ4'23

Embedded Options Available No

Max Memory Size (dependent on memory type)192 GB

Memory Types Up to DDR5 5600 MT/s
Up to DDR4 3200 MT/s

Max # of Memory Channels2

Max Memory Bandwidth89.6 GB/s

ECC Memory Supported ‡Yes

GPU Name Intel® UHD Graphics 770

Graphics Base Frequency300 MHz

Graphics Max Dynamic Frequency1.55 GHz

Graphics Outpute DP 1.4b, DP 1.4a, HDMI 2.1

Execution Units32

Max Resolution (HDMI)‡4096 x 2160 @ 60Hz

Max Resolution (DP)‡7680 x 4320 @ 60Hz

Max Resolution (eDP - Integrated Flat Panel)‡5120 x 3200 @ 120Hz

DirectX* Support12

OpenGL* Support4.5

OpenCL* Support3.0

Multi-Format Codec Engines2

Intel® Quick Sync Video Yes

Intel® Clear Video HD Technology Yes

# of Displays Supported ‡4

Device ID0xA780

Direct Media Interface (DMI) Revision4.0

Max # of DMI Lanes8

Scalability1S Only

PCI Express Revision5.0 and 4.0

PCI Express Configurations ‡Up to 1x16+4, 2x8+4

Max # of PCI Express Lanes20

Sockets SupportedFCLGA1700

Max CPU Configuration1

Thermal Solution Specification PCG 2020A

TJUNCTION100°C

Package Size45.0 mm x 37.5 mm

Intel® Gaussian & Neural Accelerator3.0

Intel® Thread Director Yes

Intel® Deep Learning Boost (Intel® DL Boost) on CPU Yes

Intel® Speed Shift Technology Yes

Intel® Turbo Boost Technology ‡2.0
