Model
MPE-8501-AFAAG
ATX Version
ATX 12V
PFC
Active PFC
Input Voltage
90-264V
Input Current
12-6A
Input Frequency
47-63Hz
Dimensions (L x W x H)
160 x 150 x 86 mm
Fan Size
120mm
Fan Bearing
HDB
Fan Speed
1500 RPM
Noise Level @ 20%
0 dBA
Noise Level @ 50%
17.8 dBA
Noise Level @ 100%
25.9 dBA
Efficiency
90% @ Typical Load
80 PLUS Rating
80 PLUS Gold
ErP 2014 Lot 3
Yes
Operating Temperature
0-50°C
Power Good Signal
100 - 150 ms
Hold Up Time
>16ms at 100% Load
MTBF
>100,000 Hours
Protections
OVP, OPP, OTP, SCP, OCP, UVP
Regulatory
TUV, CE, CCC, EAC, RCM, cTUVus, FCC, BSMI
ATX 24-Pin Connectors
1
EPS 4+4 Pin Connectors
1
EPS 8 Pin Connector
1
SATA Connectors
12
Peripheral 4-Pin Connectors
4
PCI-e 6+2 Pin Connectors
4
Serie
MWE Gold Series
80 Plus
Gold
Modular
Full Modular
Wattage
Above 850W
