Printer
|
|
Maximum Printing Resolution
|
4800 (horizontal)*1 x 1200 (vertical) dpi
|
|
Print Head / Ink
|
Number of Nozzles:
|
Total 1,472 nozzles
|
|
Ink Bottles
|
GI-790 (Black, Cyan, Magenta, Yellow)
|
|
Print Speed*2 (Approx.)
Based on ISO / IEC 24734
Click here summary report
Click here for Document Print and Copy Speed Measurement Conditions
|
Document: Col
|
ESAT / Simplex
|
5.0 ipm
|
|
Document: Mono
|
ESAT / Simplex
|
8.8 ipm
|
|
Document: Col
|
FPOT Ready/Simplex
|
19 sec
|
|
Document: Mono
|
FPOT Ready/Simplex
|
13 sec
|
|
Document: Col
|
FPOT Sleep/Simplex
|
21 sec
|
|
Document: Mono
|
FPOT Sleep/Simplex
|
14 sec
|
|
Photo (4 x 6")
|
PP-201 / Borderless
|
60 sec
|
|
Printable Width
|
Bordered:
|
Up to 203.2 mm (8 inch)
|
|
Borderless:
|
Up to 216 mm (8.5 inch)
|
|
Printable Area
|
Borderless Printing*3
|
Top / Bottom / Right / Left margin: each 0 mm (Supported Paper Size: A4 / Letter / 4 x 6" / 5 x 7" / 8 x 10" / Square (5 x 5") / Business Card)
|
|
Bordered Printing
|
Top margin: 3 mm,
Bottom margin: 5 mm,
Left / Right margin: each 3.4 mm
(Letter / Legal: Left: 6.4 mm, Right: 6.3 mm)
|
|
Recommended Printing Area
|
Top margin:
|
31.2 mm
|
|
Bottom margin:
|
32.5 mm
|
|
Paper Size
|
A4, A5, B5, Letter, Legal, 4 x 6", 5 x 7", 8x 10", Envelopes (DL, COM10), Square (5 x 5"), Business Card, Custom size (width 55 - 215.9 mm, length 89 - 676 mm)
*F4 is possible via custom size settings.
|
|
Paper Handling (Rear Tray)
(Maximum Number)
|
Plain Paper
|
A4, A5, B5, Letter = 100, Legal = 10
|
|
High Resolution Paper (HR-101N)
|
A4, Letter = 80
|
|
Photo Paper Plus Glossy II (PP-201)
|
A4, Letter = 10, 4 x 6" = 20, 5 x 7", 8 x 10" = 10, Square (5 x 5") = 20
|
|
Photo Paper Plus Semi-Gloss (SG-201)
|
A4, Letter = 10, 4 x 6" = 20, 5 x 7", 8 x 10" = 10
|
|
Matte Photo Paper (MP-101)
|
A4, Letter = 10, 4 x 6" = 20
|
|
Envelope
|
European DL / US Com. #10 = 10
|
|
Photo Paper Plus Glossy II (PP-208)
|
A4, 4 x 6" = 10
|
|
Photo Sticker
|
PS-208, PS-808 = 1
|
|
Paper Weight
|
Rear Tray
|
Plain Paper: 64 - 105 g/m2, Canon specialty paper: max. 275 g/m2 Photo Paper Plus Glossy II (PP-201)
|
|
Ink End Sensor
|
Dot count
|
|
Print Head Alignment
|
Manual
|
|
System Requirements
(Please visit https://asia.canon/support to check OS compatibility and to download the latest driver updates)
|
Windows:
|
Windows 10, Windows 8.1, Windows 7 SP1
|
|
Macintosh:
|
Mac OS is not supported
|
|
General Specifications
|
|
|
Interface
|
USB 2.0
|
|
Paper Output Tray
|
A4, Letter = 50, Legal = 10
|
|
Operating Environment*4
|
Temperature:
|
5 - 35°C
|
|
Humidity:
|
10 - 90% RH (no dew condensation)
|
|
Recommended Environment*5
|
Temperature:
|
15 - 30°C
|
|
Humidity:
|
10 - 80% RH (no dew condensation)
|
|
Storage Environment
|
Temperature:
|
0 - 40°C
|
|
Humidity:
|
5 - 95% RH (no dew condensation)
|
|
Quiet Mode
|
Available
|
|
Acoustic Noise (PC Print)*6
|
Plain Paper (A4, Mono)
|
Approx. 54.5 dB(A)
|
|
Power
|
AC 100 - 240 V; 50/60 Hz
|
|
Power Consumption (Approx.)
|
Connection to PC
|
USB
|
|
OFF:
|
0.2 W
|
|
Standby (scanning lamp is off):
(USB connection to PC)
|
0.6 W
|
|
Standby (all ports connected, scanning lamp is off)
|
0.6 W
|
|
Printing*7: G1010
|
11 W
|
|
Dimensions (W x D x H) (Approx.)
|
Factory configuration
|
445 x 330 x 135 mm
|
|
Output / ADF Trays Extended
|
445 x 529 x 253 mm
|
|
Weight (Approx.)
|
4.8 kg
|
